WELD ON BEADLOCK BOLT KIT
Included in this kit:
(128) 1 ¾ x 3/8 yellow zinc grade 8 bolts
(128) 3/8 yellow zinc grade 8 washers
(128) 3/8 nylock yellow zinc grade 8 nuts
Tools and equipment:
-eye protection glasses or face shield, hearing protection, and suggested leather gloves and anything else for safety
-ratchet with 9/16 socket and wrench
-torque wrench (suggested to get wheels evenly to help prevent air leaking)
Following steps for full outer ring kit
Step 1: Place the outer ring on the outside of the tire and insert a bolt with a washer on it threw the outer ring lining it up with the hole on the inner ring. Do this for 4 to 8 bolts evenly spaced out and hand tighten them. Make sure the tire is centered on the wheel.
Step 2: Install all the other bolts with washer and the nut on the inside of the wheel.
Step 3: Tighten all the bolts to 15 to 20 Ft/lbs recommended with a tq wrench to evenly tighten the bolts. This also helps to seal the wheel and help prevent leakage. This may take 4 to 5 times to go all the way around it is a long process but worth it in the end.
Following steps for our budget builder kit
Step 1: Take 4 outer ring pieces and put 1 bolt with washer in on each end of the 4 pieces lining the bolts up with the holes on the inner ring. These should be spaced evenly on the tire. Note: there should be approximately 1/16 to 1/8 inch gap between each of the 4 sections. Tighten the 2 bolts on each of the 4 pieces hand tight. Make sure the tire is centered on the wheel.
Step 2: Step 13: Install all the other bolts with washer and the nut on the inside of the wheel.
Step 3. : Tighten all the bolts to 15 to 20 Ft/lbs recommended with a tq wrench to evenly tighten the bolts. This also helps to seal the wheel and help prevent leakage. This may take 4 to 5 times to go all the way around it is a long process but worth it in the end.
Off-road Solutions dba All Things Off-Road and US Metal Works cannot be held responsible and do not accept liability for failures or breakage to vehicle and other components in off-road use. We cannot be held responsible or liable to modifications to your vehicle done by you or non-certified or experienced mechanics or welders. Please note that modifications to your vehicles may void warranties, and or may handle very differently both on and off road. All parts, labor, and installs should be performed by a certified professional.
Please note: Bead locks are for off-road use only and are not to be driven on public roads.
Please note: Re-torque beadlocks after 1st run. It is also recommended to periodically check the torque and at least once a year
